PCB HDMI ASS'Y
NOTE: When replacing the AVR1912E2, EA, E1C IC18 or IC41, use the AVR2112CIE3, AVR1912E3
IC18(963248100110S) or IC41(963243100070S).
When replacing the AVR1912E1C IC11, use the AVR1912E2 (EA) IC11(963248100710S).
When the following are replaced, always rewrite with updated rmware using DFW.
(Refer to "PROCEDURE FOR UPGRADING THE VERSION OF THE FIRMWARE" (45 page).)
• PCB HDMI ASSY
• IC11 (MX25L3206EM2I-12G/MX25L6406EM2I-12G)
• IC18 (H27U1G8F2BTR)
• IC22 (EPM3032A-TC44)
• IC41 (R5F64169DFDFP)
• U7 (EN29LV160BB-70TIP)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1 nsp IC EX3AV J048030030010S
IC2 231310009508S IC PQ033DNA1ZPH J126033010010S
IC3 234810015507S IC BU4248F J126424800010S
IC4-7 nsp IC EX3AV J048030030010S
IC9 943236012460S IC ADV7623 CVIADV7623BSTZ
IC11 963248100120S
IC MEMORY FLASH
(MX25L3206EM2I-12G)
2112CIE3,1912E3 8952191200040 *
IC11 963248100710S
IC MEMORY FLASH
(MX25L6406EM2I-12G)
1912E2,1912EA 8952191200060 *
IC11 nsp
IC MEMORY FLASH
(MX25L6406EM2I-12G)
1912E1C -
IC12 963239010410S IC ADV7511BSTZ-225 J040751100010S
IC13 nsp IC MFI341S2164 J044341216410S
IC14 nsp IC LAN8700-AEZG-TR J127870010010S
IC15 00D2623711004 IC LOGIC SAA7121H J045712100010S
IC16 246810063608S
IC MEMORY-RAM
(W9825G6JH-6)
J001982566010S
IC17 nsp IC,ANALOG DM860 J080860005510S
IC18 963248100110S
IC MEMORY FLASH
(H27U1G8F2BTR)
2112CIE3,1912E3 8952191200030 *
IC18 nsp
IC MEMORY FLASH
(H27U1G8F2BTR)
1912E2,1912EA,
1912E1C
-
IC19 236810062608S IC LC89058W-E J046890580020S
IC20 963239002150S IC SN74LVC244APWR J040742440230S
IC21 236810062608S IC LC89058W-E J046890580020S
IC22 943236100020S IC EPM3032A-TC44 CVIANAM1570AV
IC24 00D2623077900 IC TC74VHCU04FT J040740405580S
IC25 00D9630237503 MODULE JSR1165-C E100116500040S
IC28 00D2631289900 IC AZ4580M
2112E3,1912E3,
1912E1C
J121458000020S
IC28 00D2623555901 IC SA5532ADR 1912E2,1912EA J121553200050S
IC29 236810073509S IC AK4358VQ-L J042435800010S
IC30 236810086505S IC AK5358BET-E2 J043535805520S
IC31,32 00D2631289900 IC AZ4580M J121458000020S
IC33 236810070500S IC AK4424ET-E2 TSSOP16 J042442405520S
IC34 00D2631289900 IC AZ4580M J121458000020S
IC35 234810014504S IC MC14094BDTR2G J040140940020S
IC37 00D2623437906 IC TC74VHCT244AFT J040742445540S
IC38 00D2623444902 IC TC74VHC08FT
1912E3,1912E2,
1912EA,1912E1C
J040740800280S
IC39 00D2623444902 IC TC74VHC08FT J040740800280S
IC40 246810026500S IC R1EX24256ASAS0A J000242565550S
d
f
f
NOTE :
When update Firmware, please
conrm a last version in SDI.
Use the service board after
updating it.
NOTE : When replacing the 1912E1C parts, use the 1912E2(EA) parts.
After replacing the parts, overwrite the rmware with the newest 1912E1C version rmware.
NOTE : When replacing the 1912E2(EA) or E1C parts, use the 1912E3/2112CIE3 parts.
After replacing the parts, overwrite the rmware with the newest 1912E2(EA) or E1C version rmware.
