AVR-2802/982
38
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
PARTS LIST OF P.W.B. UNIT ASS'Y
1U-3368 POWER UNIT ASS'Y
Note : The symbols in the column “Remarks” indicate the following destinations.
EU: U.S.A. model E1: Asia model
982: AVR-982 (U.S.A.) model E1H: Hong Kong model
EC: Canada model E1C: China model
E2: Europe model EUT: Taiwan R.O.C. model
D305 276 0432 903 Diode 1SS270A
D307 276 0432 903 Diode 1SS270A
D313 276 0432 903 Diode 1SS270A
D315 276 0432 903 Diode 1SS270A
D401 276 0432 903 Diode 1SS270A
D403 276 0432 903 Diode 1SS270A
D405 276 0432 903 Diode 1SS270A
D407 276 0432 903 Diode 1SS270A
D413 276 0432 903 Diode 1SS270A
D415 276 0432 903 Diode 1SS270A
D501,502 276 0338 007 Diode S4VB20F
D504-509 276 0704 903 Diode 1SR35-400A(T93X)
D510 276 0432 903 Diode 1SS270A
D601,602 276 0432 903 Diode 1SS270A
D604,605 276 0432 903 Diode 1SS270A
D607 276 0432 903 Diode 1SS270A
ZD101,102 276 0460 904 Zener diode HZS5C-1TD
ZD103,104 276 0461 903 Zener diode HZS6A-1TD
ZD201,202 276 0460 904 Zener diode HZS5C-1TD
ZD203,204 276 0461 903 Zener diode HZS6A-1TD
ZD301 276 0460 904 Zener diode HZS5C-1TD
ZD303 276 0461 903 Zener diode HZS6A-1TD
ZD401 276 0460 904 Zener diode HZS5C-1TD
ZD403 276 0461 903 Zener diode HZS6A-1TD
ZD503 276 0465 912 Zener diode HZS7B-2TD
ZD504 276 0645 907 Zener diode MTZJ18A
SC501 279 0016 904 Thyristor SF0R1A42
RESISTORS GROUP
R113,114 241 2379 987 Carbon film 1 kohm 1/4W(NB) RD14B2E102JNBST
R119,120 241 2379 987 Carbon film 1 kohm 1/4W(NB) RD14B2E102JNBST
R123,124 241 2378 920 Carbon film 220 ohm 1/4W(NB) RD14B2E221JNBST
R125,126 244 2671 914 Metal oxide 15 kohm 2W(NB)
RS14B3D153JNBST(S)
R127,128 241 2378 946 Carbon film 270 ohm 1/4W(NB) RD14B2E271JNBST
R129,130 241 2378 920 Carbon film 220 ohm 1/4W(NB) RD14B2E221JNBST
R137-140 241 2376 964 Carbon film 47 ohm 1/4W(NB) RD14B2E470JNBST
R141-148 244 2671 956 Metal oxide 0.47 ohm 2W(NB) RS14B3DR47JNBST(S)
R213,214 241 2379 987 Carbon film 1 kohm 1/4W(NB) RD14B2E102JNBST
R219,220 241 2379 987 Carbon film 1 kohm 1/4W(NB) RD14B2E102JNBST
R223,224 241 2378 920 Carbon film 220 ohm 1/4W(NB) RD14B2E221JNBST
R225,226 244 2671 914 Metal oxide 15 kohm 2W(NB)
RS14B3D153JNBST(S)
R227,228 241 2378 946 Carbon film 270 ohm 1/4W(NB) RD14B2E271JNBST
SEMICONDUCTORS GROUP
IC501 263 1100 018 IC KIA7806API
IC502 268 0073 905 IC ICP-N15
TR101,102 273 0459 903 Transistor KTC2874B
TR103-106 271 0094 919 Transistor 2SA970(BL)
TR107,108 273 0281 906 Transistor 2SC2705(O)/(Y)
TR109,110 271 0168 900 Transistor 2SA1145 (O)/(Y)
TR111,112 273 0281 906 Transistor 2SC2705(O)/(Y)
TR117,118 273 0458 904 Transistor 2SC/KTC3200BL
TR201,202 273 0459 903 Transistor KTC2874B
TR203-206 271 0094 919 Transistor 2SA970(BL)
TR207,208 273 0281 906 Transistor 2SC2705(O)/(Y)
TR209,210 271 0168 900 Transistor 2SA1145 (O)/(Y)
TR211,212 273 0281 906 Transistor 2SC2705(O)/(Y)
TR217,218 273 0458 904 Transistor 2SC/KTC3200BL
TR301 273 0459 903 Transistor KTC2874B
TR303 271 0094 919 Transistor 2SA970(BL)
TR305 271 0094 919 Transistor 2SA970(BL)
TR307 273 0281 906 Transistor 2SC2705(O)/(Y)
TR309 271 0168 900 Transistor 2SA1145 (O)/(Y)
TR311 273 0281 906 Transistor 2SC2705(O)/(Y)
TR317 273 0458 904 Transistor 2SC/KTC3200BL
TR401 273 0459 903 Transistor KTC2874B
TR403 271 0094 919 Transistor 2SA970(BL)
TR405 271 0094 919 Transistor 2SA970(BL)
TR407 273 0281 906 Transistor 2SC2705(O)/(Y)
TR409 271 0168 900 Transistor 2SA1145 (O)/(Y)
TR411 273 0281 906 Transistor 2SC2705(O)/(Y)
TR417 273 0458 904 Transistor 2SC/KTC3200BL
TR501 271 0094 919 Transistor 2SA970(BL)
TR502 271 0131 924 Transistor 2SA988(E/F)
TR503 273 0429 904 Transistor 2SC3311A
TR504 271 0192 905 Transistor 2SA933S(S)
TR505,506 273 0429 904 Transistor 2SC3311A
TR507 271 0192 905 Transistor 2SA933S(S)
TR508,509 273 0429 904 Transistor 2SC3311A
TR510 273 0303 910 Transistor 2SC1740S(S)
TR511 269 0020 906
Transistor DTC114ES(10K-10K)
D101-108 276 0432 903 Diode 1SS270A
D113-116 276 0432 903 Diode 1SS270A
D201-208 276 0432 903 Diode 1SS270A
D213-216 276 0432 903 Diode 1SS270A
D301 276 0432 903 Diode 1SS270A
D303 276 0432 903 Diode 1SS270A
