AVR-2803/983/AVC-2870
1U-3470 CONNECT/VIDEO UNIT ASS'Y(Except Japan model)
Ref.No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC251,252 262 2826 903 BU4051BCF
IC253,254 263 1082 903 TK15420MTL
IC255 262 2012 908 BU4052BCF-E2
IC256 262 2013 907 BU4053BCF-E2
IC257,258 263 1082 903 TK15420MTL
IC451 262 2827 902 MM74HC4053SJ
IC452 263 0682 003 NJM2229S
IC453 262 2808 002 M35015-210SP
IC501-503 263 1082 903 TK15420MTL
IC504-507 262 2826 903 BU4051BCF
IC508 263 1082 903 TK15420MTL
IC509,510 262 2012 908 BU4052BCF-E2
IC511,512 263 1082 903 TK15420MTL
IC701 262 2114 903 UPD4721GS-GJG
IC703 262 3174 900 SN74AHCT08NS
TR401,402 269 0048 904 DTC143EK-T96
TR455,456 273 0464 901 KTC3875SGR-RTK
TR501 271 0312 905 2SA/KTA1504SGR-RTK
TR502,503 269 0082 902 DTC114EKT96
TR601 271 0301 903 2SA/KTA1268BL-AT
TR602,603 273 0464 901 KTC3875SGR-RTK
TR604 271 0312 905 2SA/KTA1504SGR-RTK
TR605,606 273 0464 901 KTC3875SGR-RTK
TR607 271 0312 905 2SA/KTA1504SGR-RTK
TR608,609 273 0464 901 KTC3875SGR-RTK
TR610 271 0312 905 2SA/KTA1504SGR-RTK
TR611 273 0464 901 KTC3875SGR-RTK
TR901 271 0301 903 2SA/KTA1268BL-AT
TR902 274 0160 907 2SD2144STPU
TR903 273 0458 904 2SC/KTC3200BL-AT
TR904,905 271 0301 903 2SA/KTA1268BL-AT
TR906-910 269 0083 901 DTA114EKT96
TR911 271 0301 903 2SA/KTA1268BL-AT
TR912 269 0083 901 DTA114EKT96
TR913 271 0301 903 2SA/KTA1268BL-AT
TR956,957 269 0083 901 DTA114EKT96
D251,252 276 0432 903 1SS270A TE (TAPE)
D401,402 276 0432 903 1SS270A TE (TAPE)
D453 276 0560 901 DAN202KT146
D459 276 0432 903 1SS270A TE (TAPE)
D501,502 276 0432 903 1SS270A TE (TAPE)
D901-910 276 0723 900 RB721Q-40
D911 276 0432 903 1SS270A TE (TAPE)
D913 276 0704 903 1SR35-400A(T93X)
D914 276 0484 919 HZS33-2TD
D915 276 0704 903 1SR35-400A(T93X)
D916 276 0461 916 HZS6A-2TD
D917 276 0704 903 1SR35-400A(T93X)
D918-921 276 0723 900 RB721Q-40
ZD701 276 0461 903 HZS6A-1TD
ZD702 276 0477 926 HZS16-3TD
Note:
The symbols in the column ”Remarks” indicate
the following destinations.
EU : U.S.A. model E1C : China model
EC : Canada model E1H : Hong Kong model
E2 : Europe model EUT : Taiwan R.O.C. model
E1 : Asia model E1K : Korea model
