Denon AVR-2803 Service Manual

80
80
AVR-2803/983/AVC-2870
1U-3486D AUDIO/DIGITAL UNIT ASS'Y(For Japan model)
Ref.No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC101,102 262 2545 006 TC9274N-011
IC205 263 0898 907 NJM5532MD-TE1
IC207 263 0896 909 NJM2068MD-TE1
IC301 262 2919 001 TC9274N-017
IC302 263 0896 909 NJM2068MD-TE1
IC361 263 0896 909 NJM2068MD-TE1
IC371 262 3165 003 TC94A27UG *
IC372 263 1074 908 OP275GSR
IC374 263 1074 908 OP275GSR
IC376 262 3165 003 TC94A27UG *
IC377 263 0898 907 NJM5532MD-TE1
IC379 263 0898 907 NJM5532MD-TE1
IC501-504 269 0209 002 GP1FA352RZ
IC506 269 0210 004 GP1FA352TZ
IC508 262 2729 903 SN74LV02APW-EL2
IC509 262 3224 009 AD1835 *
IC510-512 262 3077 900 TC74VHCU04FT
IC513,514 262 2944 908 SN74HC151APW-EL2
IC515 262 3176 908 74VHC74MTCX
IC518,519 263 0934 900 BA4510F-E2
IC520 262 3066 102 LC89057W-VF4-E(AC)
IC521 262 3233 906 FCX0-03L(12.288MHZ)
IC522 262 2959 906 SN74LV244APW
IC527 263 0898 907 NJM5532MD-TE1
IC529 263 0898 907 NJM5532MD-TE1
IC531 263 0896 909 NJM2068MD-TE1
IC533 263 0896 909 NJM2068MD-TE1
IC535 263 0898 907 NJM5532MD-TE1
IC801,802 262 3175 909 74VHC00MTCX
IC803 262 3176 908 74VHC74MTCX
IC804 262 2870 904 74LVX157MTC
IC805 263 1164 009 PQ018EF01SZ
IC806 262 3151 004 TMP91CP27U-4NB4 *
IC807 262 2517 908 SN74LV08APW-EL2
IC809 263 1048 002 BA033T
TR501 269 0082 902 DTC114EKT96
TR502 269 0083 901 DTA114EKT96
TR503 269 0082 902 DTC114EKT96
TR504 269 0083 901 DTA114EKT96
TR517,518 273 0460 905 KTC2875B-RTK
TR519 269 0082 902 DTC114EKT96
TR520 269 0083 901 DTA114EKT96
TR521-536 273 0460 905 KTC2875B-RTK
TR801 272 0161 900 2SB1412TL(PQR)
TR802 269 0082 902 DTC114EKT96
TR803 269 0083 901 DTA114EKT96
TR804,805 269 0082 902 DTC114EKT96
D502,503 276 0738 908 KDS226-RTK(A-K)
CAPACITORS GROUP
C105 247 2018 903 RM73B--0R0KT
C107-109 247 2018 903 RM73B--0R0KT
C110 257 0509 929 CK73B1H102KT
