AVR-2803/983/AVC-2870
PARTS LIST OF P.W.B UNIT ASS'Y(For Japan model)
1U-3469J POWER UNIT ASS'Y(For Japan model)
Ref.No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC201 263 1035 002 PQ30RV11
! IC502 268 0073 905 ICP-N15T
TR105,106 273 0458 904 2SC/KTC3200BL-AT
TR107 273 0464 901 KTC3875SGR-RTK
TR205 273 0458 904 2SC/KTC3200BL-AT
TR207 273 0464 901 KTC3875SGR-RTK
TR305,306 273 0458 904 2SC/KTC3200BL-AT
TR307,308 273 0464 901 KTC3875SGR-RTK
TR405,406 273 0458 904 2SC/KTC3200BL-AT
TR407 273 0464 901 KTC3875SGR-RTK
TR501 271 0094 919 2SA970(BL)TPE2
TR507 273 0464 901 KTC3875SGR-RTK
TR509,510 273 0464 901 KTC3875SGR-RTK
TR511 269 0082 902 DTC114EKT96
TR601-608 273 0460 905 KTC2875B-RTK
TR611-618 273 0460 905 KTC2875B-RTK
D101-107 276 0432 903 1SS270A TE (TAPE)
D201 276 0432 903 1SS270A TE (TAPE)
D203 276 0432 903 1SS270A TE (TAPE)
D205 276 0432 903 1SS270A TE (TAPE)
D207 276 0432 903 1SS270A TE (TAPE)
D301-308 276 0432 903 1SS270A TE (TAPE)
D401-407 276 0432 903 1SS270A TE (TAPE)
D501,502 276 0338 007 S4VB20F
D503-506 276 0704 903 1SR35-400A(T93X)
D507 276 0432 903 1SS270A TE (TAPE)
D508,509 276 0704 903 1SR35-400A(T93X)
ZD101-104 276 0461 903 HZS6A-1TD
ZD201 276 0461 903 HZS6A-1TD
ZD203 276 0461 903 HZS6A-1TD
ZD301-304 276 0461 903 HZS6A-1TD
ZD401-404 276 0461 903 HZS6A-1TD
ZD503 276 0465 912 HZS7B-2TD
ZD504 276 0645 907 MTZJ18A T77
RESISTORS GROUP
R103-106 241 2376 964 RD14B2E470JNBST
R107-114 244 2671 956 RS14B3DR47JNBST(S)
R125,126 244 2682 903 RS14B3D010JNBST(S) *
R127,128 244 2671 901 RS14B3D100JNBST(S)
R203 241 2376 964 RD14B2E470JNBST
R205 241 2376 964 RD14B2E470JNBST
R207 244 2671 956 RS14B3DR47JNBST(S)
R209 244 2671 956 RS14B3DR47JNBST(S)
R211 244 2671 956 RS14B3DR47JNBST(S)
R213 244 2671 956 RS14B3DR47JNBST(S)
R214 245 2365 980 RN14K2E391FT(5)
R225 244 2682 903 RS14B3D010JNBST(S) *
R227 244 2671 901 RS14B3D100JNBST(S)
R303-306 241 2376 964 RD14B2E470JNBST
R307-314 244 2671 956 RS14B3DR47JNBST(S)
R325,326 244 2682 903 RS14B3D010JNBST(S) *
