System call function
• The included remote control unit is equipped with a system call function for transmitting multiple remote control signals when a single button
is pressed (this is often referred to as a “macro” function).
This function can be used to turn on the amplifier’s power, select the input source, turn on the monitor TV’s power, turn on a source
component’s power and start playback, etc., all at the touch of a button.
(1) System call buttons
The buttons that can be used for the system call function are shown on the table below.
A series of up to 10 operations can be performed with the POWER ON and OFF buttons, and a series of up to 5 operations can be performed
with other buttons.
System call signals are already preset at the buttons indicated in the shaded section. System call signals can also be stored at any button on
the remote control unit, including the buttons in this section. (See page 36.)
Button
No.
transmissions
Stored
operation 1
Receiver
power on
Receiver
power on
Receiver
power on
Receiver
power on
Receiver
power on
Stored
operation 2
DVD player
(DVD)
power on
LD player
(VDP)
power on
TV power on
Video (VCR)
power on
Receiver
input source
switched to
CD
Stored
operation 3
Receiver
input source
switched to
DVD
Receiver
input source
switched to
VDP
Receiver
input source
switched to
TV/DBS
Receiver
input source
switched to
VCR-1
Stored
operation 4
TV power on
TV power on
TV power on
Stored
operation 5
Stored
operation 6
Stored
operation 7
Stored
operation 8
Stored
operation 9
Stored
operation 10
DVD player
(DVD)
playback
LD player
(VDP)
playback
Video (VCR)
playback
POWER OFF 10
POWER ON 10
DVD 5
VDP
TV/DBS
VCR-1
CD
5
5
5
5
The system call signals for the POWER OFF and
POWER ON buttons are transmitted from the
remote control unit approximately once every
second.
The signals for the other buttons (DVD, VDP, TV /
DBS, VCR-1 and CD) are transmitted approximately
once every 1.5 seconds.
(2) Using the system call function
1
Press the system call button.
• The LEARNED/TX LED flashes for 5 seconds.
CALL
2
Press the button at which the desired system call signals are
stored while the LEARNED/TX LED is flashing.
• The preset signals or the signals you have stored at that
button are transmitted in succession.
DVD
START LEARNED/TX
SPEAKER
TUNING
BAND
TITLE
MENU/GUIDE
MODE
MEMORY
USE/LEARN T.TONE MULTI OUTPUT SET UP
RETURN
STATUS
DISPLAY
ON SCREEN
DOLBY / DTS
SURROUND
DIRECT
DSP SIMULATION 5CH STEREO STEREO
INPUT MODE ANALOG EXT.IN
MUTING
MASTER VOL.
VOLUME DISC SKIP+
SYSTEM CALL POWER
VDP TUNER SHIFT
TV/DBS PHONO
VCR-1 CD
MD / TAPE CHANNEL
VCR-2/V.AUX
TV/VCR
AVR/AVC VIDEO DVD TV
AUDIO
VDP VCR
CD
MD
MULTI
DECK
SYSTEM
SETUP
SURROUND
PARAMETER
CH SELECT
SELECT
RC-860
123
4
SET
A / B
CALL OFF
ENTER
ON / SOURCE
56
789
+10
0
2
1

Denon AVR-3300 Specifications

Audio Specifications

rated output (front)	105 W + 105 W (8 Ω, 20 Hz ~ 20 kHz with 0.05% T.H.D.)
rated output (center)	105 W (8 Ω, 20 Hz ~ 20 kHz with 0.05% T.H.D.)
dynamic power	140 W x 2 ch (8 Ω)
input sensitivity / input impedance	200 mV / 47 kΩ
frequency response (analog)	10 Hz ~ 50 kHz: +0, –3 dB (DIRECT mode)
S/N (analog)	102 dB (DIRECT mode)
distortion (analog)	0.01% (20 Hz ~ 20 kHz) (DIRECT mode)
D/A output (rated)	2 V (at 0 dB playback)
total harmonic distortion (digital)	0.008% (1 kHz, at 0 dB)
S/N ratio (digital)	102 dB
dynamic range (digital)	96 dB
phono input sensitivity	2.5 mV
RIAA deviation	±1 dB (20 Hz to 20 kHz)
signal-to-noise ratio (phono)	74 dB (A weighting, with 5 mV input)
distortion factor (phono)	0.03% (1 kHz, 3 V)

Video Specifications

input / output level and impedance (standard video)	1 Vp-p, 75 Ω
frequency response (standard video)	5 Hz ~ 10 MHz — +0, –3 dB
input / output level and impedance (S-video)	Y signal — 1 Vp-p, 75 Ω; C signal — 0.286 Vp-p, 75 Ω
frequency response (S-video)	5 Hz ~ 10 MHz — +0, –3 dB
input / output level and impedance (color component video)	Y signal — 1 Vp-p, 75 Ω; Cb/Cr signal — 0.7 Vp-p, 75 Ω
frequency response (color component video)	5 Hz ~ 20 MHz — +0, –3 dB

Tuner Specifications

receiving range (FM)	87.50 MHz ~ 107.90 MHz
receiving range (AM)	520 kHz ~ 1710 kHz
usable sensitivity (FM)	1.0 µV (11.2 dBf)
50 dB quieting sensitivity (MONO)	1.6 µV (15.3 dBf)
S/N (IHF-A) (MONO)	80 dB
total harmonic distortion (MONO)	0.15% (at 1 kHz)

General Specifications

power supply (North America model)	AC 120 V, 60 Hz
power consumption (North America model)	5.6 A
maximum external dimensions	434 (W) x 171 (H) x 416 (D) mm
weight	15.0 kg (33 lbs 2 oz)
batteries (remote control)	R6P/AA Type (two batteries)
external dimensions (remote control)	70 (W) x 215 (H) x 24 (D) mm
weight (remote control)	200 g (Approx. 7 oz) (including batteries)
