37
ENGLISH
Clearing “learned” remote control signals and resetting the preset memory
1
Press the USE/LEARN selector button with the tip of a pen,
etc., to set the learn mode.
2
To clear “learned” remote control signals, set the slide switch
to the position at which the signals were “learned”. To clear
the preset memory settings, set the slide switch to “VIDEO”.
3
Set the slide switch to the position at which the signals were
“learned” or at which the preset memory settings were set.
DVD TV
VDP VCR
CD
MD
MULTI
DECK
DVD
START LEARNED/TX
SPEAKER
TUNING
BAND
TITLE
MENU/GUIDE
MODE
MEMORY
USE/LEARN T.TONE MULTI DVD
SET UP
RETURN
STATUS
DISPLAY
ON SCREEN
DOLBY / DTS
SURROUND
DIRECT
DSP SIMULATION
5CH STEREO STEREO
INPUT MODE
ANALOG EXT.IN
MUTING
MASTER VOL.
VOLUME DISC SKIP+
SYSTEM CALL POWER
VDP TUNER SHIFT
TV/DBS PHONO
VCR-1 CD
MD
/
TAPE
CHANNEL
VCR-2/V.AUX
TV/VCR
AVR/AVC VIDEO DVD TV
AUDIO
VDP VCR
CD
MD
MULTI
DECK
SYSTEM
SETUP
SURROUND
PARAMETER
CH SELECT
SELECT
RC-860
123
4
SET
A / B
CALL OFF
ENTER
ON
/
SOURCE
56
789
+10
0
4
2
1,5
3
OUTPUT
4
Press the SYSTEM CALL SET button, and hold it in for at least
four seconds.
• When both the START and LEARNED/TX LEDs light
simultaneously, all the stored codes are cleared.
5
Press the USE/LEARN selector button.
9
OPERATION
Before operating
1
Refer to “CONNECTIONS” (pages 7 to 14) and check that all
connections are correct.
2
Set the remote control unit’s slide switch to the AUDIO
position. (only when operating with the remote control unit)
3
Turn on the power.
Press the POWER switch (button).
(Main unit) (Remote control unit)
Light
for multiple voltage model
• ¢ ON/STANDBY
The power turns on and “ON/STANDBY” indicator is light.
Several seconds are required from the time the power switch is set to the “ON” position until sound is output. This is due to the built-in muting
circuit that prevents noise when the power switch is turned on and off.
Set the POWER switch to this position to turn the power on and off from the included remote control unit (RC-860).
• £ OFF
The power turns off and “ON/STANDBY” indicator is off.
In this position, the power cannot be turned on and off from the remote control unit.
DVD
START LEARNED/TX
SPEAKER
TUNING
DOLBY / DTS
SURROUND
DIRECT
DSP SIMULATION
5CH STEREO STEREO
INPUT MODE
ANALOG EXT.IN
MUTING
MASTER VOL.
VOLUME DISC SKIP+
SYSTEM CALL POWER
VDP TUNER SHIFT
TV/DBS PHONO
VCR-1 CD
MD
/
TAPE
CHANNEL
VCR-2/V.AUX
TV/VCR
AVR/AVC VIDEO DVD TV
AUDIO
VDP VCR
CD
MD
MULTI
DECK
SYSTEM
SETUP
SURROUND
PARAMETER
RC-860
123
4
SET
A / B
CALL OFF
ON
/
SOURCE
56
789
+10
0
2
3
for North American model
When pressed, the power turns on and the display lights. The sound
is muted for several seconds, after which the unit operates normally.
When pressed again, the power turns off, the standby mode is set
and the display turns off.
Whenever the ON/STANDBY button is in the STANDBY state, the
apparatus is still connected on AC line voltage. Please be sure to
unplug the cord when you leave home for, say, a vacation.
