Denon AVR-390 Service Manual

55
DHT-390XP
AVR-390
AMP P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q201C 00D9600196205 TR KSA992F
J5000992F0050S
Q201FL 00D9600196205 TR KSA992F J5000992F0050S
Q201FR 00D9600196205 TR KSA992F J5000992F0050S
Q201SL 00D9600196205 TR KSA992F J5000992F0050S
Q201SR 00D9600196205 TR KSA992F J5000992F0050S
Q202C 00D9600196205 TR KSA992F J5000992F0050S
Q202FL 00D9600196205 TR KSA992F J5000992F0050S
Q202FR 00D9600196205 TR KSA992F J5000992F0050S
Q202SL 00D9600196205 TR KSA992F J5000992F0050S
Q202SR 00D9600196205 TR KSA992F J5000992F0050S
Q203C 00D9600196700 TR KTC3200BL J5023200B0050S
Q203FL 00D9600196700 TR KTC3200BL J5023200B0050S
Q203FR 00D9600196700 TR KTC3200BL J5023200B0050S
Q203SL 00D9600196700 TR KTC3200BL J5023200B0050S
Q203SR 00D9600196700 TR KTC3200BL J5023200B0050S
Q207C 00D9600196700 TR KTC3200BL J5023200B0050S
Q207FL 00D9600196700 TR KTC3200BL J5023200B0050S
Q207FR 00D9600196700 TR KTC3200BL J5023200B0050S
Q207SL 00D9600196700 TR KTC3200BL J5023200B0050S
Q207SR 00D9600196700 TR KTC3200BL J5023200B0050S
D201C 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D201FL 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D201FR 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D201SL 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D201SR 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D202C 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D202FL 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D202FR 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D202SL 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D202SR 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D203C 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D203FL 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D203FR 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D203SL 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D203SR 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD201C 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD201FL 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD201FR 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD201SL 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD201SR 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD202C 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD202FL 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD202FR 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD202SL 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD202SR 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
RESISTORS GROUP
R211C 00D9609010719 R,METAL FILM 47-J,1W
C060047065060S
R211FL 00D9609010719 R,METAL FILM 47-J,1W C060047065060S
R211FR 00D9609010719 R,METAL FILM 47-J,1W C060047065060S
R211SL 00D9609010719 R,METAL FILM 47-J,1W C060047065060S
