Denon AVR-390 Service Manual

59
DHT-390XP
AVR-390
FRONT P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC700 963239003150S IC SC16315
J127163150010S
Q702 963219003170S TR KRA105S(PE) J520010500210S
Q703,704 00D9630120801 TR KRC102S J522010200210S
Q705 90M-BA001650R TR KRC105S (NE) J522010500210S
Q706,707 00D9630148508 TRKTA1504S J520015040150S
D701-704 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD701 00D9630314206 D,ZENER MTZJ7.5B K06007R544520S
CAPACITORS GROUP
C701 00D9630293602 C,ELECT 1UF-M/50V (Pb Free)
D040010087150S
C702,703 00D9630021900 C,FILM 0.047UF-J/100V D02047306C060S
C704 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C705 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C706 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C707,708 nsp C,CERAMIC CHIP HIK 820PF-K/50V D011821777160S
C709 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C710 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C711 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C712 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C713 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C713L nsp C,CERAMIC 220PF-J/50V D010221167160S
C713R nsp C,CERAMIC 220PF-J/50V D010221167160S
C714,715 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C716 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C718,719 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C720-722 nsp C,CERAMIC 100PF-J/50V D010101167160S
C735L 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C735R 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
OTHERS PARTS GROUP
BD701,702 963115003230S COIL,BEAD CBW160808U121T
D340160811210S
CN702 nsp CN,WIRE 2MM 480/5P L002481050010S
CN704 nsp CN.WAFER 5P L101100030510S
CN705 nsp CN,WIRE 80MM/5P L002800050100S
CN706 nsp CN,WIRE 80MM/3P L002800030110S
CP304A nsp CN.WAFER 5P L101100040510S
CP304B nsp CN.WAFER 5P L101100040510S
CP701 nsp CN.WAFER 3P ANGLE L102526803010S
CP704 nsp CN.WAFER 5P L101100030510S
CP706 nsp CN.WAFER 3P L101200100320S
L701 nsp COIL INDUCTOR 100UH D330101001020S
L702 nsp COIL INDUCTOR 10UH D330100700520S
RMC701 00D9630217808 MODULE,REMOCON NJL34H380A E940343800010S
SW701-706 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
