Denon AVR-390 Service Manual

69
DHT-390XP
PARTS LIST OF EXPLODED VIEW
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
BKE3 : U.S.A. & Canada model (
Black model)
BKE2 : Europe model (Black model) SPE2 : Europe model (Premium Silver model)
AVR-390
Ref. No. Part No. Part Name Remarks Q'ty New
30A nsp MAIN P.W.B UNIT ASSY BKE3 7025HK0810010 1*
30A nsp MAIN P.W.B UNIT ASSY BKE2
7025HK0810020 1*
30A nsp MAIN P.W.B UNIT ASSY SPE2
7025HK0810030 1*
30 - MAIN UNIT
11 - ST-BY UNIT
14 - H/P UNIT
27 - GUIDE1 UNIT
26 - GUIDE2 UNIT
21 - GUIDE3 UNIT
20 nsp AMP P.W.B UNIT ASSY BKE3
7025HK0810011 1*
20 nsp AMP P.W.B UNIT ASSY BKE2
7025HK0810021 1*
20 nsp AMP P.W.B UNIT ASSY SPE2
7025HK0810031 1*
13A nsp FRONT P.W.B. UNIT ASSY BKE3
7025HK0810012 1*
13A nsp FRONT P.W.B. UNIT ASSY BKE2
7025HK0810022 1*
13A nsp FRONT P.W.B. UNIT ASSY SPE2
7025HK0810032 1*
13 - FRONT UNIT
4 - V.AUX UNIT
17 - ENCODER UNIT
12 - TACT-SW UNIT
5-CNT UNIT
31 nsp VIDEO P.W.B. UNIT ASSY BKE3
7025HK0810013 1*
31 nsp VIDEO P.W.B. UNIT ASSY BKE2
7025HK0810023 1*
31 nsp VIDEO P.W.B. UNIT ASSY SPE2
7025HK0810033 1*
29 nsp POWER P.W.B. UNIT BKE3
7025HK0810014 1*
29 nsp POWER P.W.B. UNIT BKE2
7025HK0810024 1*
29 nsp POWER P.W.B. UNIT SPE2
7025HK0810034 1*
32 nsp DSP P.W.B. UNIT ASSY BKE3
7025HK0810015 1*
32 nsp DSP P.W.B. UNIT ASSY BKE2
7025HK0810025 1*
32 nsp DSP P.W.B. UNIT ASSY SPE2
7025HK0810035 1*
33 nsp HDMI P.W.B. UNIT ASSY BKE3
7025HK0810016 1*
33 nsp HDMI P.W.B. UNIT ASSY BKE2
7025HK0810026 1*
33 nsp HDMI P.W.B. UNIT ASSY SPE2
7025HK0810036 1*
1 963409002790S COVER RCA BKE3,BKE2
4317211691010S 1
1 00D9630264408 COVER RCA SPE2
4317211691110S 1*
2 963412000560D KNOB VOLUME(KD) BKE3,BKE2
5080211751000SZ 1
2 963412002920S KNOB VOLUME SPE2
5087211891000S 1
3 963411002810S BUTTON 4KEY BKE3,BKE2
5097213731000S 2*
3 963411002930S BUTTON 4KEY SPE2
5097213731100S 2*
6 963416002800D WINDOW DISPLAY
5077212663000S 1*
7 00D9630362109 BADGE DENON BKE3,BKE2
5630210028300S 1
AVR-390
