Denon AVR-390 Service Manual

63
DHT-390XP
AVR-390
DSP P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401 00D9630133005 IC AK4588 (Pb Free)
J080458800010S
IC402 00D9630367307 IC SN74AHCU04PWR J040740400290S
IC403 00D9630278203 DSP MICRO PROCESS
(IC CS494003-CQZ)
8952390000020
IC404 963248003200D IC ES29LV800ET-70TG
J005298000120S
IC406 00D9630366500 IC KIA1117PI33 J126111733050S
IC407,408 00D2631100005 IC KIA7805API J126780500110S
IC409 90M-HC900120R IC LM1117S-2.5V J126111725030S
IC410 963235000480S IC SN74AHCTO8-EL2 J040740800240S
D401-405 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D408-410 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
CAPACITORS GROUP
C401 00D9630293806 C,ELECT 100UF-M/10V (Pb Free)
D040101082090S
C402 00D9639005901 C,ELECT 470UF-M/10V D040471082060S
C403-405 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C406 00D9630293806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C407 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C410 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C412 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C417 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C418 00D9630294106 C,ELECT 2.2UF-M/50V (Pb Free) D0402R2087160S
C419 nsp C,CERAMIC 1200PF-K/50V D011122777160S
C420 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C421 00D9630293806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C422-424 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C427,428 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C430 00D9630293806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C431 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C435,436 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C443,444 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C445 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C446,447 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C448 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C449 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C450 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C451 963134003210S C,ELECT 220UF-M/10V (Pb Free) D040221082090S
C452 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C453 963134003210S C,ELECT 220UF-M/10V (Pb Free) D040221082090S
C454,455 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C456 nsp C,CERAMIC 100PF-J/50V D010101167160S
C457 00D9630293806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C458 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C459 00D9630293806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C460 nsp C,CERAMIC 0.047UF-K/16V D011473773160S
C461 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C462 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C463,464 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C465 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C466 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C467 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
NOTE :
When update Firmware, please
confirm a last version in SDI.
Use the service board after
updating it.
