Denon AVR-390 Service Manual

65
DHT-390XP
AVR-390
HDMI P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC01 963239003220S IC SIL9185
J040918500020S
IC03 00D9630295309 IC LM1117S-1.8V J126111718020S
IC04 00D9630300702 IC LM1117S-3.35V J126111733030S
Q01,02 00D9630120801 TR KRC102S J522010200210S
Q03,04 00D9600285006 TR KRC104S J522104S00210S
Q07 00D9600285006 TR KRC104S J522104S00210S
Q18,19 00D9600285006 TR KRC104S J522104S00210S
D44 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD101 00D9630382500 D,ZENER 0.2W 5.1V UDZ K06605R14P400S
CAPACITORS GROUP
C01 nsp C,CERAMIC 1000PF-K/50V
D011102777160S
C02-05 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C06,07 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C08-14 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C15-17 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C18,19 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C20 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C21 nsp C,CERAMIC 100PF-J/50V D010101167160S
C22 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C23 nsp C,CERAMIC 100PF-J/50V D010101167160S
C24,25 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C26,27 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C28H 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C29H 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C30H 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C33 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C34 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C35 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C36 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C37 nsp C,CERAMIC 1000PF-K/50V D011102777160S
OTHERS PARTS GROUP
BKT01,02 nsp BRACKET 0.8t/SCREW
4010210196100S
CB01,02 963115003230S COIL,BEAD CBW160808U121T D340160811210S
CB03 00D9630223009 R,THICK 0-J,1/16W C20000006M160S
CB06 963115003230S COIL,BEAD CBW160808U121T D340160811210S
CN01 nsp CN,WIRE 9P L002500090020S
JACK01-03 nsp CN.WAFER 19P L109100190030S
