Deye SUN2000G3-EU-230 User Manual

Easy to install
You can install individual PV modules in any combination of module number, orientation, different
types and power rates. The earth wire (PE) of the AC cable is connected to the enclosure inside the
microinverter, which may eliminate the need to install an earth wire (check local regulations).
Data collection is done via internal WiFi, a wireless router is required near the micro inverter. After
completing the installation of the micro inverter, configure the WLAN router with the internal WLAN
(see WLAN user manual). The data will be uploaded automatically. Users can monitor and manage
the micro inverter via the corresponding website or APP.
Introduction to microinverters
The microinverters can be connected to the single-phase grid and several microinverters can also be
used in the form of a single-phase grid to achieve a three-phase grid.
Modell-No.
AC network
Max. Number per branch
SUN300G3-EU-230 50/60Hz, 230V 17 for 25A LS-switch
SUN500G3-EU-230 50/60Hz, 230V 10 for 25A LS-switch
SUN600G3-EU-230 50/60Hz, 230V 8 for 25A LS-switch
SUN800G3-EU-230 50/60Hz, 230V 6 for 25A LS-switch
SUN1000G3-EU-230 50/60Hz, 230V 5 for 25A LS-switch
SUN1300G3-EU-230 50/60Hz, 230V 4 for 25A LS-switch
SUN1600G3-EU-230 50/60Hz, 230V 4 for 45A LS-switch
SUN2000G3-EU-230 50/60Hz, 230V 3 for 45A LS-switch
DEYE SUN microinverter
User manual
- 05

Deye SUN2000G3-EU-230 Specifications

General

Brand	Deye
Model	SUN2000G3-EU-230
Category	Inverter
Language	English
