Service - 76 FX20 Operator’s Manual
12,000 Mile
CMW
12,000 Mile
Trailer
Inspect brake shoes and linings
Inspect shoes and linings every 12 months or
12,000 miles (20 000 km) for wear. When lining is
worn to 1/16” (2 mm) or less, replace linings.
Replace shoe and lining if contaminated by oil.
Adjust and Lubricate Bearings
1. Place adequate jack stands under frame rails
and remove wheels.
2. Remove rubber plug from end of grease cap
(1).
3. Place grease gun onto grease fitting (shown).
4. Pump grease into fitting. Old grease will
come out of fitting. Stop adding grease when
new grease comes out of fitting.
5. Remove grease gun, wipe off excess grease and install rubber cap.
Location Task Notes
Trailer Inspect brake shoes and linings
Adjust and lubricate bearings
IMPORTANT: Rotate hub while adding
grease.
To Next Page
