dji A3 User Manual

A3/A3Pro
User Manual
32
©
2016 DJI. All Rights Reserved.
Triple Modular Redundancy
With two additional IMU Pro and GPS-Compass Pro modules, the A3 Pro provides triple modular
redundancy, improving the system’s anti-risk performance. System status is indicated by LEDs on
the GPS-Compass Pro, IMU Pro and Flight Controller modules.
aircraft nose will automatically change to the recorded orientation during ight.
Consistent with record: Aircraft nose orientation keep the same as the route direction. The aircraft
nose will automatically change during ight.
If the detected battery level is too low, the aircraft will not enter the Waypoints flight
mode.
IOSD
DJI Lightbridge 2 MUST be connected to for the built-in iOSD to work. Most ight information is
displayed on-screen in the DJI GO app.
Information displayed includes battery level/voltage, ight velocity, height, distance from the home
point, horizontal attitude, GPS satellite number, etc. iOSD and video information are superposed
on the receiver, making iOSD data clearly visible and bringing you a more involved flight
experience.
A3/A3 Pro supports DJI iOSD Mark II and iOSD mini.
Blinks Twice
Blinks Once
Blinks Three Times

dji A3 Specifications

Flight Performance

hovering accuracy (vertical)	±0.5 m
hovering accuracy (horizontal)	±2 m
max wind resistance	10 m/s
max yaw angular velocity	150°/s
max pitch angle	35°
max ascent velocity	6 m/s
max descent velocity	6 m/s

Power and Environment

power consumption	Max 21 W (Typical Value: 0.41 A @ 51 V)
operating temperature	14° to 113° F (-10° to 45° C)
