dji A3 User Manual

A3/A3Pro
User Manual
34
©
2016 DJI. All Rights Reserved.
Flight Safety
It is important to understand basic ight guidelines for the safety of both you and those around
you. Refer to the Disclaimer and Safety Guidelines for more information.
Appendix
LED Indicators
Flight Status LED Indicator
LED Description
Blinking Red, Green and Yellow
Alternatively
The system is running a diagnostic test.
×4 Blinking Yellow Four Times The system is warming up.
Blinking Green Slowly Safe to y, GPS working
Blinking Yellow Slowly P-ATTI or ATTI mode
×2 Blinking Green Quickly Twice VPS working, no GPS
Blinking Purple Twice Manual mode
Blinking Blue (Alternates with ight
mode patterns)
Positioning with D-RTK
Blinking Blue Rapidly for 1.5 seconds
Switching devices (IMU or GPS modules)
for the modular redundancy system
Blinking Green Rapidly for 1.5 seconds
Home Point/POI/Course Orientation is set
successfully
Blinking Yellow (Alternates with other
ight mode and D-RTK patterns)
Intelligent Flight Modes
Blinking Yellow Rapidly
Remote controller signal lost
Blinking Red Slowly Low battery warning
Blinking Red Rapidly Critically low battery warning
Blinking Red Rapidly for 0.6 second
when performing CSC
Large IMU bias or IMU initialization
—— Solid Red Critical error
Blinking Red and Yellow Alternatively Compass calibration required

dji A3 Specifications

Flight Performance

hovering accuracy (vertical)	±0.5 m
hovering accuracy (horizontal)	±2 m
max wind resistance	10 m/s
max yaw angular velocity	150°/s
max pitch angle	35°
max ascent velocity	6 m/s
max descent velocity	6 m/s

Power and Environment

power consumption	Max 21 W (Typical Value: 0.41 A @ 51 V)
operating temperature	14° to 113° F (-10° to 45° C)
