Operation Elite Control

7.5 Navigation Tree

This section shows the menu navigation for the Elite

Control.

OPERATING MODES

Cool Mode

Heat Mode

Dehumidiﬁcation Mode

Aux Heat Mode

Automatic Mode

FAN MODES

Fan Mode

Manual Fan Mode

Fan-Only Mode

Cycled/Continuous Fan Mode

FAULT CODES

HPF High Pressure Fault

LPF Low Pressure Fault

PLF Pump Sentry Fault

ASF Inside Sensor Failure

FIL Clean/Replace Filter

SAH High Supply Air Temp

LC/UL Lock/Unlock Keypad

LSF Sea Water Low Limit

LAC Low AC Voltage

FAULT HELP

Air Sensor Fault

High Pressure Fault

Low Pressure Fault

Low AC Fault

Pump Sentry Fault

DX PROGRAMMABLE PARAMETERS

P-1 High Fan Limit

P-2 Low Fan Limit

P-3 Compressor Staging Time Delay

P-4 Inside Air Temperature Sensor Calibration

P-5 Failsafe Level

P-6 Low Voltage Monitor

P-7 De-Icing Cycle

P-8 Optional Pump Sentry

P-9 Display Brightness Control

P-10 Fahrenheit or Celsius Selection

P-11 Cycle Pump with Compressor

P-12 Reverse Automatic Fan Speeds During Heating

P-13 Auxiliary Heat Enable

P-14 Fan Motor Selection

P-15 Restore Factory Default Settings

P-16 Reserved

P-17 Reserved

P-18 Air Filter Cleaning/Replacement Timer Setting

P-19 Filter Cleaning/Replacement Timer Value & Reset

P-20 CAN Bus Unit ID

P-21 CAN Bus Group ID

P-22 Voltage Calibration

P-23 Set Point Temperature Diﬀerential

P-24 Dehumidiﬁcation Mode Minimum Temperature

P-25 Auto Fan Speed Temperature Diﬀerential

P-26 Supply Air High Temperature Limit

P-27 Seawater Low Limit Adjustment

P-28 Relative Humidity Enable

P-29 High-Pressure Switch Test

P-30 Low-Pressure Switch Test

P-31 Reserved

P-32 Medium Fan Speed

P-33 Cool-Only Mode

CW PROGRAMMABLE PARAMETERS

P-1 High Fan Limit

P-2 Low Fan Limit

P-3 Reserved

P-4 Inside Air Temperature Sensor Calibration

P-5 Reserved

P-6 Reserved

P-7 Reserved

P-8 Reserved

P-9 Display Brightness Control

P-10 Fahrenheit or Celsius Selection

P-11 Reserved

P-12 Reverse Automatic Fan Speeds During Heating

P-13 Auxiliary Heat Enable

P-14 Fan Motor Selection

P-15 Restore Factory Default Settings

P-16 Hydronic Water Valve Forced Open

P-17 Water Temperature Diﬀerential

P-18 Air Filter Cleaning/Replacement Timer Setting

P-19 Filter Cleaning/Replacement Timer Value & Reset

P-20 CAN Bus Unit ID

P-21 CAN Bus Group ID

P-22 Voltage Calibration

P-23 Set Point Temperature Diﬀerential

P-24 Dehumidiﬁcation Mode Minimum Temperature

P-25 Auto Fan Speed Temperature Diﬀerential

P-26 Supply Air High Temperature Limit

P-27 Reserved

P-28 Relative Humidity Enable

P-29 High-Pressure Switch Test

P-30 Low-Pressure Switch Test

P-31 Reserved

P-32 Medium Fan Speed

P-33 Reserved

DISPLAY ICONS

Fan Fan Modes

Mode Operating Modes

Mode+Down Fault Log

Mode+Up Programming Menu

Fan+Up Seawater Temp.

Up+Down+Mode Relative Humidity

(DX) Fan+Down Compressor

Run-Time Meter
