Dometic Elite Control Series User Manual

5
EN
Elite Control Specifications
4.2 Cable Length
Display Cable
Self-Contained
15.0  (4.6 m) Standard
Inside Air Temperature
Sensor (optional)
7.0  (2.1 m) Standard
OAT Sensor (optional) 15.0  (4.6 m) Standard
All custom cable lengths
are supplied in standard
5  (1.5 m) increments
75.0  (22.9 m) Maximum
4.3 Available System Inputs
Water Inlet
Temperature Sensor
(CW Installations Only)
1
High Refrigerant Pressure 1
Inside Air Temperature
Sensor (optional)
1
Low Refrigerant Pressure
(optional)
1
OAT Sensor (optional) 1
Pump Sentry Water
Sensor (optional)
(DX Installations Only)
1
Room Temperature/
Relative Humidity
Combination Sensor
(optional)
1
4.4 Operational Specifications
Set Point Operating
Range
65 °F to 85 °F (18 °C to 29 °C )
Ambient Temperature
Operating Range
Displayed
5°F to 150°F (-15°C to 66°C)
Sensor Accuracy ± 2°F @ 77°F (±1°C @ 25°C)
Low Voltage Limit
100–120 V
95 VAC
Low Voltage Limit
200–240 V
195 VAC
Low Voltage Processor
Reset
50 VAC
Universal Line Voltage 100–240 VAC
Frequency 50 Hz or 60 Hz
Fan Output
6 A @ 115 VAC
6 A @ 230 VAC
Valve Output 5 A @ 115/230 VAC
For CW Only:
Auxiliary Electric
Heater Output
(using compressor
output L1 and L2)
30 A Maximum
External Triac 26 A
External Q-Relay 30 A Maximum
Pump Output
1/4 HP @ 115 VAC
1/2 HP @ 230 VAC
Compressor Output
1 HP @ 115 VAC
2 HP @ 230 VAC
Minimum Operating
Temperature
0°F (-18°C)
Maximum Ambient
Operating Temperature
180°F (82°C)
Maximum Rh Conditions 99% Non-condensing
Power Consumption < 5 W

Dometic Elite Control Series Specifications

General

Brand	Dometic
Model	Elite Control Series
Category	Control Unit
Language	English
