Fastening and connecting the inverter PerfectPower
12
Rear view (fig. 2, page 3)
8 Fastening and connecting the inverter
8.1 Fastening the inverter
!
You can fasten the inverter using the holders supplied.
When selecting the installation location, observe the following instructions:
• Do not operate the device
– in wet or damp environments
– in dusty environments
– in the vicinity of flammable materials
– in spaces where there is a danger of explosion
• Do not expose the device to a heat source (such as direct sunlight or heating).
Avoid additional heating of the device in this way.
• Make sure the cables are the correct length and choose the installation location
near the battery supply.
No. Description
1 Main switch
2 Connection for MCR9 remote control
3 Connection for an external switch contact
4 Earth connection
5Fan
6 Negative terminal
7 Positive terminal
WARNING!
• Ensure the device is standing firmly.
Set up the device securely and fasten it in such a way that
– it cannot tip over or fall down
– it cannot move while the vehicle is in motion
• Take precautions necessary to ensure that it is out of reach of
children. Dangerous situations may occur which cannot be
recognised by children!
PP1000-PP2000--IO-16s.book Seite 12 Mittwoch, 3. August 2016 6:19 18
