PerfectPower Fastening and connecting the inverter
13
• Select a well-ventilated location for the device.
A ventilation system must be present for installations in small, enclosed spaces.
• Make sure that the air intake on the front of the inverter remains clear.
• Select a mounting surface which is flat and sufficiently firm.
Fasten the inverter as follows (fig. 5, page 4):
A
➤ Clip two holders on the left bar and two on the lower right bar.
You can move the holders as required.
➤ Fasten the inverter by screwing one screw through each hole in the holder.
8.2 Connecting the inverter
!
Observe the following safety instructions for the electrical connections:
A
NOTICE!
Before drilling any holes, make sure that no electrical cables or other
parts of the vehicle can be damaged by drilling, sawing and filing.
WARNING!
The inverter may only be connected by a qualified workshop.
The following information is intended for specialists who are familiar with
the guidelines and safety precautions to be applied.
NOTICE!
• Caution – Risk of short circuit!
When working on the vehicle, always disconnect the earth
connection to the supply battery.
• Disconnect the 230 V external power supply to the caravan.
• If you have to feed cables through metal walls or other walls with
sharp edges, use ducts or tubes to prevent damage.
• Do not lay cables which are loose or bent next to electrically
conductive material (metal).
• Fasten the cables securely.
• Do not pull on the cables.
• Do not lay the 230 V mains cable and the 12/24 V DC cable in the
same duct.
• Lay the cables so that they cannot be tripped over or damaged.
PP1000-PP2000--IO-16s.book Seite 13 Mittwoch, 3. August 2016 6:19 18
