25
EN
Refrigerator
5.7 Connecting the water supply
For refrigerator models equipped with ice maker, ice and water dispensers:
➤ Ensure that the water supply system has a minimum pressure of 15 pounds per square-inch (psig).
➤ Use a 1/4" diameter water line to the water valve at the rear of the refrigerator.
➤ Ensure that the water line is equipped with a manual shut-off valve that is easily accessible.
6 INSTALLATION
6.1 Installing the refrigerator
I
Refrigerator model RM1350SL is equipped with vacuum-insulated panel technology. The insulating
panels are located on the top, back, sides, and doors. If the surface is punctured, the effectiveness of the
insulation will be reduced, resulting in poor refrigerator performance.
36
Apply sealing strip to floor
Do NOT remove factory
installed sealing strip
*RM2351, RM2354
Seal
Seal
➤ Carefully place the refrigerator in the enclosure.
➤ Verify that there is a complete seal between the front frame of the refrigerator and the top, sides and bottom
of the enclosure.
I
A length of sealing strip is applied to the rear surface of the front frame of the refrigerator. The sealing strip
provides complete isolation of the combustion system from the vehicle interior.
➤ RM2351, RM2354: Apply a sealing strip to the front edge of the enclosure floor. Do not damage the
sealing strip when the refrigerator is put in place.
I
RM2351 & RM2354: Do not remove the factory-installed sealing strip at the top rear corner of the
cabinet. It is not part of the shipping materials and must be le intact.
