Dometic RM2354 Installation Manual

26
EN
Refrigerator
6.2 Securing the refrigerator
I
The following steps must be completed in order to prevent leakage between the refrigerator and the
enclosure.
RM2351, RM23514
37
Plug
Screw
Front
Frame
Seal
Rear
Base
Do NOT
remove
factory-
installed
sealing
strip
➤ Install four screws (not provided) through the front
frame.
➤ Install one screw (not provided) in the rear base.
➤ Cover the screw heads using the plugs provided
RM2451, RM2454, RM2551, RM2554, DM2652,DM2662, DM2663, DM2852, DM2862
38
Screw
Lower
Front
Strip
Front
Base
Rear
Base
➤ Install the lower front strip by sliding it under the
bottom hinge plate. Refer to "6.3 Installing the
hinge plate" on page 29.
➤ Secure the refrigerator and the lower front strip
using two screws (not provided).
39
Top Panel
Hinge
➤ Gently remove the tabs from the hole in the
hinge plate, on both sides, using a flat-bladed
screwdriver.
➤ Tilt the top decoration panel and li to remove it
from the top frame. Do not damage the circuit
board and wires.
➤ Install two screws (not provided) in the top frame.
➤ Seal the opening for the screws with aluminum
tape (not provided).
➤ Replace the top decoration panel. Do not pinch
the wires behind the panel.
