28 Dräger X-dock 5300/6300/6600
Technical data
11 Technical data 12 Order list
Dimensions (H x W x D):
Master approx. 3.54 x 5.70 x 9.84 inches
(120 x 130 x 250 mm)
Module approx. 3.54 x 5.70 x 9.84 inches
(90x145x250mm)
Weight:
Master
approx. 4.02 pounds
(48.23 ounces; 1500 g)
Module
approx. 2.57 pounds
(30.86 ounces; 960 g)
Ambient conditions:
During operation
During storage
32 °F to +104 °F (0 °C to +40 °C)
4°F to+122°F (-20°C to+50°C)
700 to 1300 hPa
max. 95% relative humidity
Gas connections: 1x fresh air connection
1x compressed air inlet
1x exhaust outlet
X-dock 5300/6300 3x gas inlets
X-dock 6600 6x gas inlets
Inlet pressure:
for the measured gas 0.5 bar ±20 %
for compressed air 0.5 bar ±20 %
Power supply: 11 V - 28 V DC, 6.25 A
Connections: 3x USB 2.0 standard A
connection, (host, cable <3 m)
1x USB 2.0 mini-B connection,
(device, cable <3 m)
1x Ethernet port RJ45
Data rate 10/100 Mbit
Serial no. (year of
manufacture):
The year of construction is given
by the 3rd letter in the factory
number located on the nameplate:
B=2010, C=2011, D=2012,
E=2013, F=2014, G=2015,
H=2016, etc.
Example: Serial number ARFH-
0054, the 3rd letter is F, so the
year of construction is 2014.
CE mark: Electromagnetic compatibility
(Directive 2004/108/EC)
Name and description
Order No.
Dräger X-dock 5300 X-am 125 83 21 880
Dräger X-dock 5300 Pac 83 21 881
Dräger X-dock 6300 Master 83 21 900
Dräger X-dock 6600 Master 83 21 901
Dräger X-dock Module X-am 125 83 21 890
Dräger X-dock Module X-am 125+
(with charge function)
83 21 891
Dräger X-dock Module Pac 83 21 892
Single wall mount 83 21 922
Comfort wall mount 83 21 910
Cylinder holder (table-top version) 83 21 918
Cylinder holder for top-hat rail 83 21 928
Power pack 24 V / 1.33 A (up to 3 modules) 83 21 849
Power pack 24 V / 6.25 A (up to 10 modules) 83 21 850
X-dock car adapter 83 21 855
Pressure regulator valve 0.5 bar
(nickel-plated)
83 24 250
Pressure regulator valve 0,5 bar,
Flowstop
83 24 251
Pressure regulator valve 0.5 bar
(stainless steel)
83 24 252
Hose clamp, 5 pce. 83 24 095
Pump filter set (includes filter and hose
connector)
83 19 364
Fluorinated rubber hose 12 03 150
Sealing insert (X-am) 83 21 986
Sealing insert (Pac) 83 21 987
X-dock Master display protector film 83 21 804
Stickers for module numbering 83 21 839
Barcode label, exterior (22 x 8 mm, 500
labels)
AG02551
Barcode scanner 83 18 792
Dräger X-dock Manager Basic 83 21 860
Dräger X-dock Manager Professional 83 21 870
Dräger X-dock Manager Licence
(1x, both versions)
83 21 857
Dräger X-dock Manager Licence
(5x, both versions)
83 21 858
