dynabook C50-J-12A Instructions

1. Removing the Lithium Ion Battery (Main Battery, No coin cell battery)
Please refer to the information below for instructions regarding the identification and removal of
the lithium ion battery. Further maintenance instructions can be found in section 4.2 of the
Satellite C50-J / Satellite Pro C50-J Maintenance Manual. Some tools are required in order
to remove this component. Once removed, these components should be recycled as per local
requirements.
To remove the battery, the base assembly must be removed first:
Removing Base Enclosure
Remove Base Enclosure according to the following procedures and Figure 4-7.
1. Remove seven M2.0x7.5x4.5black Phillips head screws securing Base
Enclosure and four M2.0x.3.5x4.5black Phillips head screws securing
Base Enclosure.
2. Remove Base Enclosure.
Figure 4-7 Removing Base Enclosure

dynabook C50-J-12A Specifications

General

Brand	dynabook
Model	C50-J-12A
Category	Laptop
Language	English
