NOTE:
Be sure to place all cables into the ditch to avoid the damage during
assembling the bottom cover.
NOTE:
Be sure to align Type-C connector to Top Cover, when place system board on
the unit.
Install System Board according to the following procedures and Figures 4-21.
1.
Place System Board in correct position.
2.
Securing System Board with four M2.0x3.0x4.5and one M2.0x2.5x5.0
black Phillips head screw.
( ▲ mark portions)
3.
Connect following cable to the connector on System Board:
-
Speaker cable from SPK.
-
LCD cable from CN6.
-
IO Board cable from CON19
-
FFC-MB terminal connected to TP-CON1
-
keyboard connection KBCON1,over the speaker wire wiring. -
FAN cable from CN21.
-
Battery Pack cable from CN3.
-
RTC Battery from RTCCN1.
-
Released wireless antenna cables from top cover latch. - Place System Board in
correct position
-
DC block paste high temperature adhesive paper
