UPS SYSTEM INSTALLATION
Eaton 9395 UPS (450–825 kVA) Installation and Operation Manual S 164201725 Rev 4 www.eaton.com/powerquality
4-41
11. Reinstall the front door removed in Step 3 and secure with the retained
hardware.
12. Close the door and secure the latch.
X-Slot Communication Bays
TB3
TB1 and TB2
(See Figure 4‐35
for detail.)
(See Figure 4‐37 on
page 4-44 for terminal
assignments.)
(See Figure 4‐40 on
page 4-47 for detail.)
ISBM
Figure 4‐34. ISBM Section Interface Terminal Locations
