Eaton 93E UPS 15-80 kVA (380/400/415 V) Installation and Operation Manual
© Eaton Corporation plc 2015. All rights reserved. Revision: 001
Document ID: 614-01975-00
102 (133)
The bypass status indicator is illuminated. The power module
remains on.
WARNING
Power is present inside the UPS cabinet.
7.3.5 Transfer from the standard normal mode to the HE mode
To transfer the load to the HE mode:
1. Select the
symbol in the main menu bar.
The System Control screen is displayed.
2. If not already selected, select
in the System Control screen.
3. In the UPS System Control screen, select the
→
command and press the push button.
After the battery is fully charged, the UPS transfers to the HE mode
if no abnormal power conditions are detected.
If abnormal power conditions are detected, the UPS waits and
transfers to the HE mode when the conditions are cleared.
The normal mode status indicator is illuminated.
7.3.6 Transfer from the HE mode to the standard normal mode
To transfer the load to the standard normal mode:
1. Select the
symbol in the main menu bar.
The System Control screen is displayed.
2. If not already selected, select
in the System Control screen.
3. In the UPS System Control screen, select the
→
command and press the push button.
The UPS transfers to the standard normal mode.
The normal mode status indicator is illuminated.
