Eaton 9PHD User Manual

• For detailed instruction on wiring, refer to the Site Planning Data.
• Refer to national and local electrical codes for acceptable external wiring
practices.
• To allow for future kVA upgrades (software and/or hardware), consider using
conductors sized for full bypass rating of the UPS.
• Material and labor for external wiring requirements are to be provided by
designated personnel.
• For external wiring, use copper cable rated for 70°C at minimum. See the
appropriate information in Table
7 and Table 8 . Refer to the UPS type plate
for the input and output voltages of the UPS. Cable sizes are based on using
the specified breakers.
• If cables are run in an ambient temperature greater than 30°C, higher
temperature cable and/or larger size cable may be necessary.
WARNING
Do not disconnect the neutral of a supply without disconnecting the phases at
the same time.
• Neutral wire must be sized according to the load. With non-linear load
equipment, neutral wire with a rating of 1.7 times the phase wire is
recommended.
• A readily accessible disconnect device must be incorporated in all fixed input
wiring.
Table 7: Minimum recommended multi-core cable and fuse sizes for rectifier input and by-
pass input connection, 9PHD 30–100 kW UPS
Input supply
line-to-line voltage [V]
UPS rating [kW]
30 40 50 80 100
208 Phase cables [mm
2
] 1 x 50 1 x 70 1 x 95 1 x 185 1 x 240
Rectifier and bypass
fuse [A]
125 160 200 315 400
Protective bonding cable
[mm
2
]
1 x 25 1 x 35 1 x 50 1 x 95 1 x 120
230 Phase cables [mm
2
] 1 x 50 1 x 70 1 x 95 1 x 185 1 x 240
Rectifier and bypass
fuse [A]
125 160 200 315 400
Protective bonding cable
[mm
2
]
1 x 25 1 x 35 1 x 50 1 x 95 1 x 120
380 Phase cables [mm
2
] 1 x 16 1 x 25 1 x 35 1 x 70 1 x 95
Rectifier and bypass
fuse [A]
63 80 100 160 200
Protective bonding cable
[mm
2
]
1 x 16 1 x 16 1 x 16 1 x 35 1 x 50
Eaton 9PHD Accessory Cabinets TFC-A, EBC-F
and EBC-G User's and installation guide
©
Eaton Corporation plc 2022. All rights reserved. Document ID: P-164000538 43 (63)
