Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02 7
Table 4. LCD Operating Status (Continued)
Operation status Cause Description
Battery mode
A utility failure has occured and the UPS
is on Battery mode.
The UPS is powering the equipment with
the battery power. Prepare your
equipment for shutdown.
End of backup time
The UPS is on Battery mode and the
battery is running low.
Low Battery Warning settings:
[Capacity] [0%] ... [100%]
[Runtime] [0mn] ... [60mn]
The alarm triggers when the set
percentage of battery capacity or
remaining back-up time is reached.
High Efficiency mode
The UPS is operating on High Efficiency
mode.
The UPS is powering and protecting the
equipment
Bypass mode
An overload or a fault has occurred, or a
command has been received, and the
UPS is in Bypass mode.
Equipment is powered but not protected
by the UPS.
22..66 DDiissppllaayy FFuunnccttiioonnss
Press the ( ) button to activate the menu options. use the two middle buttons ( and ) to scroll through
the menu structure. Press the (
) button to select an option. Press the ESC button to cancel or return to the
previous menu.
Table 5. Display Functions
Main menu Submenu Display information or Menu function
Measurements
[Load] W VA A pf / [Input/Output] V Hz /
[Efficiency] % / [Battery] % min V n°
EBM / [Battery remaining life] months /
[Average power usage] Wh / [Cumulated
power] Wh / BMS Information
Control Go to Bypass Transfers the UPS on Bypass mode
Load segments On/Off Commands the load segments
Start battery test Starts a manual battery test
Connectivity test Tests dry contact relay outputs and relay
card contacts. Simulates line failure and
battery low
Function reset Clears active fault, power usage, battery
remaining life, reset NMC, Restore
factory settings.
Settings Local settings Sets product general parameters
