High Efficiency mode
The UPS is running in High
Efficiency mode.
Bypass mode
An overload or fault has occurred, or
a convert to bypass command has
been received, and the UPS is in
Bypass mode.
2.6 Display functions
Press the Enter ( ) key to open the menu options. Use the two keys in the middle ( and ) to scroll
through the menu options. Press the Enter ( ) key to select a menu option. Press the ESC key to cancel
the action or go back to the previous menu.
Main menu
Sub-menu
Displayed information or menu functions
Measurement
[Load] W VA A pf/[Input/Output] V Hz/
[Efficiency] %/[Battery] % min V n°[Remaining Battery Life] months/
[Output Energy per Hour] Wh/[Total Energy] Wh
Control
Force Bypass
The UPS is switched to Bypass mode.
Partition
Settings
Controls the outputs of Load Partition 1 and Partition 2.
Battery Self-test
Starts a manual battery test.
Equipment
Connection Test
Tests the dry contact output and riser card connection to simulate mains
overrange and low battery voltage.
Reset Test
Clears faults, outputs energy, displays battery life, resets the NMC,
restores the factory settings.
Settings
Local Settings
Sets the general parameters of the local machine.
Input/Output
Settings
Sets the input/output parameters.
On/Off Settings
Sets the on/off conditions.
Battery Settings
Sets the battery configuration.
Communication
Settings
Sets the communication parameters.
Event Log
Event settings
Selects the faults, warnings, and events to be displayed.
Event Log
Displays stored events.
Clear Event Log
Clears events.
Fault Log
Fault Log
Displays stored faults.
Clear Fault Log
Clears faults.
Information
[Model] [Lot No./Serial No.] [UPS/NIC Driver] [NIC IPv4] [NIC IPv6] [NIC
MAC]
Product
Registration
Please register products at: www.eaton.com/pq
