4 Eaton 9PX Lithium-Ion User Guide DPD-9PX2206—Rev 01
Table 3. UPS Accessories (Continued)
Part number Description
EMPDT1H1C2 Environmental Monitoring Probe Gen 2 (Compatible with
NETWORK-M2 only)
MBP6K208 Hotswap MBP 6000 208
9PXTFMR5 5kVA Transformer
9PXPPDM1
6kVA PPDM (Type 1)
9PXPPDM2
6kVA PPDM (Type 2)
EBMCBL192–L
1.8m cable 192V EBM
22..33 RReeaarr PPaanneellss
Figure 2. 9PX6K-L
RS232 communication port
USB communication port
Dry (relay)contacts communication port
Connector for ROO (Remote On / Off) control
Connector for communicating with an additional battery module
Connector for RPO (Remote Power Off) control
Slot for optional communication card
Connector for additional battery module
(2) L6-20R outlets
(2) L6-30R outlets
Input / Output terminal blocks
Connector for Hotswap / MBP detection
Input power cable with L6-30 plug
Rear Panels
