Eaton 9PX Lithium-Ion User Guide DPD-9PX2206—Rev 01 5
Figure 3. 9PXEBM192RT-L
  
Connectors for battery modules
(to the UPS or to the other battery
modules)
Connector for communicating
with an additional battery module
Battery breaker
  
22..44 CCoonnttrrooll PPaanneell
The UPS has a five-button graphical LCD. It provides useful information about the UPS itself, load status, events,
measurements and settings.
Online mode
indicator (green)
Fault
indicator (red)
Online mode
100%
30min
1EBM
50%
2.7kW
3.0kVA
Efficiency: 95 %
Escape Up Down Enter On/Off
button
Battery mode
indicator (orange)
Bypass mode
indicator (orange)
Control Panel
