16 Eaton 9PX Lithium-Ion User Guide DPD-9PX2206—Rev 01
Figure 9. UPS Rackmount Installation
1
2
3
4
4
5
Screw back in the metal protection cover, connect the BMS connector together and install the screws for the
front panel, then clip the center cover.
The rails and necessary hardware are supplied by EATON.
33..66 IInnssttaallllaattiioonn RReeqquuiirreemmeennttss
Recommended protective devices and cable cross-sections.
1. Recommended upstream protection
UPS Power Rating
Upstream circuit breaker
6000VA D curve — 30A
Installation Requirements
