Table 10. Electrical Input (Continued)
Model Default Input
(Voltage/Max Current)
Input Nominal Voltages Input Voltage Window at
Rated Load
Frequency Range
50Hz : 40-60Hz before transfer to battery
60Hz : 50-70Hz before transfer to battery
Bypass Voltage Range
-20% / +15% of nominal value (default)
Noise Filtering MOV for normal and common mode noise
Table 11. Electrical Input Connections
Model Input Connection
9PX6K-L L6-30P cord or Hardwired
Table 12. Electrical Output
All Models Normal Mode Battery Mode
Voltage Regulation ±1% ±1%
Efficiency
> 98% (High Efficiency mode)
>93%
> 91%
Frequency Regulation Sync with line ±5% of nominal line
frequency (outside this range: ±0.5% of
auto-selected nominal frequency)
±0.5% of auto-selected nominal
frequency
Nominal Output
200*/208*/220*/230*/240V (voltage configurable)
6000VA* 4500/5400W*
Frequency 50 or 60 Hz, autosensing or configurable as a frequency converter
Output Overload
100-102% : no alarm
102-110% : load transfers to Bypass mode after 2 minutes
110-125% : load transfers to Bypass mode after 1 minute
125-150% : load transfers to Bypass mode after 10s
> 150% : load transfers to Bypass mode after 500ms
Output Overload ( Bypass Mode )
100-125% : no alarm
125-150% : UPS shuts down after 1 minute
> 150% : UPS shuts down after 1s
Voltage Waveform Sinewave
Harmonic Distortion
< 2% THDV on linear load
< 5% THDV on non-linear load
Transfer Time
Online Mode: 0ms (no break)
High Efficiency mode: 10ms maximum (due to loss of utility)
Power Factor Up to 0.9
Load Crest Ratio Up to 3:1
Model Specifications

Eaton 9PX6K-L Specifications

General

Brand	Eaton
Model	9PX6K-L
Category	UPS
Language	English
