Appendix A
Specifications
Copyright © 2008-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-68D February 2010
51
Appendix A
Specifications
DC Input
Nominal voltage 48Vdc
Operating range 40.5Vdc ~ 58Vdc
Under voltage warning
threshold
45Vdc
Under voltage threshold 40Vdc
Over voltage warning threshold
58Vdc
Over voltage threshold 60Vdc
Isolation AC-DC Reinforced isolation (Pri-Sec) 4242Vdc/1min
Inrush current <2*I
rated
Isolation DC-enclosure 707Vdc (Varistors and filter capacitor removed)/1min
Input protection Reverse Polarity Protection
Psophometric noise voltage ≤1.0mV ITU-T O.41 (16.66 ~ 6000Hz)
Reflected Psophometric noise
current
According to YD /T 777-2006 less than 1%
Reflected relative band wide
current noise
According to YD/T 777~2006 less than 10%(0-2Mhz)
Wide Band Noise <1.0mVpsof (25Hz~5kHz)
<20mVrms (25Hz~20kHz)
Peak to peak noise 150mV up to 100MHz
Protection
Over load When load exceeds 125% or 150% 0r 200% of power capacity,
inverter will shut down 20s or 10s or 5s later, and diagnose
as overload fault with red LED lit.
When load is 100~125%, inverter continuously delivers
output power with a yellow LED lit for warning.
Output Voltage Fault Detection When the output RMS (root mean square) voltage is out of
operating voltage range, the inverter unit will diagnose as
output voltage high or low fault.
Inverter output short circuit When output is short, the system will shut down and the red
LED will be on.
Input Voltage Detection When the DC input voltage is out of operating voltage range,
the inverter system will shut down and release visual and
audio alarms.
Over Temperature When inverter internal temperature rises over 100°C (212°F),
the system will diagnose as over temperature fault with red
LED flicker.
