IM02602002E
www.eaton.com Page 3-1
MP-3000
Nominal Voltage: 120 Vac or 240 Vac
(+10%, -25%)
Operating Range: 120 Vac: 90-132 Vac
240 Vac: 180-264 Vac
Interruption Ride-through Time: Complete drop of power for
minimum of 13 cycles at
nominal 60 Hz control power
voltage, and 11 cycles
at nominal 50 Hz control
power voltage
Frequency: 60 Hz nominal, 57-63 Hz
50 Hz nominal, 47-53 Hz
Power Consumption: 24 VA max
URTD: 6 VA max
IPONI: 1 VA max
Nominal (I
n
): 1 A or 5 A
CT Rating: 2 x I
n
continuous
50 x I
n
for 1 second
CT Burdens: < 0.25 VA @ 5 A (nominal)
< 0.05 VA @ 1 A (nominal)
Phase Current Accuracy: ± 1% of I
n
(from 0 to I
n
A)
± 1% of reading
(from I
n
to I0I
n
A)
Ground Current Accuracy: ± 1.5% of I
n
(0 to 55% of I
n
A)
± 2% of I
n
(55% I
n
to I
n
A)
± 2% of reading (from I
n
to
4 I
n
A)
Number of inputs: 2 programmable
Rating: 1.2 VA @ 120 Vac
Maximum off = 36 Vac
Minimum on = 86 Vac
Number of Outputs: 4 form C, programmable
Momentary: Make 30 A ac/dc for 0.25 sec.
Break 0.25 A @ 250 Vdc
(resistive)
Break 5 A @ 120/240 Vac
Continuous: 5 A @ 120/240 Vac
5 A @ 30 Vdc
Rating: ± 4 to 20 mA, programmable
Maximum Load: 1 kilohm
Accuracy: 1%
2
Full Load Amps: 10 to 3,000 A
Locked Rotor Current: 300 to 1,200% FLA
Locked Rotor Time: 1 to 120 sec.
Ultimate Trip Current: 85 to 150% FLA
Phase CT ratio: 10 to 4,000: I
n
Ground CT ratio: 10 to 4,000: I
n
Timing Accuracy: The greater of ± 2.5% or ± 100
ms for current > 1.1 X UTC
Ground Fault (GF): Off, 2% to 55% of CT ratio
primary
GF Start Delay: 2 to 60 cycles
GF Run Delay: 0 to 60 cycles
Timer Accuracy: ± 2.5 cycles, -1/2 cycle
Instantaneous Overcurrent: Off, 300 to 1,600% FLA
IOC Start Time Delay: 2 to 60 cycles
Timer Accuracy: ± 2.5 cycles, -1/2 cycle
Jam Trip: Off, 100 to 1,200% FLA
Underload Trip: Off, 6 to 90% FLA
Phase Unbalance Trip (I): Off, I
2
/I
1
= 4 to 40%
Start Delay Timers: 0 to 120 sec. - underload and
phase unbalance
0 to 1,200 sec. - jam
Run Delay Timers: 0 to 240 sec.
Timer Accuracy: ± .5% + 250 ms
For phase unbalance, add
200 ms for zero setting
For underload, add 480 ms for
zero setting
Ground Fault: Off, 2% to 55% CT Ratio
Overload I
2
t: Off, 60 to 99% I
2
t
Jam: Off, 100 to 1,200 %FLA
Underload: Off, 6 to 90% FLA
Phase Unbalance: Off, 4 to 40% I
2
/I
1
Run Delay Timers: Off, 0 to 240 sec.
Starts per Time: 1 to 10 starts
Time for Starts per Time: Off, 1 to 240 minutes
Time Between Starts: Off, 1 to 240 minutes
Number of Cold Starts: 1 to 5 starts
Motor Transition Current: 10 to 300% FLA
Time for Transition: 0 to 1,200 sec.
Incomplete Sequence Timer: Off, 1 to 240 sec.
Long Acceleration Timer: Off, 1 to 1,200 sec.
Antibackspin Timer: Off, 1 to 3,600 sec.
Sensor Types: 10 ohm copper
100 ohm nickel
120 ohm nickel
100 ohm platinum
Interface: Plastic optical ber
(preferred)
Electrical (3-wire)
Fiber Optic Cable: Type HFBR-ELS (length) -
precut low-loss with
connectors
Type HBFR-EUS (length) -
bulk low-loss without
connectors
Type HBFR-RLS (length) -
standard-loss, acceptable
for <10 m
