the new state ashes on the display for ve seconds, and the display
returns to the value being monitored.
The Monitor mode displays real-time data as listed in Table 4.2.
For example, to view the motor bearing temperatures:
Press the Monitor pushbutton; the display shows MONITOR
as listed at the top of Table 4.2.
Press the Page up button once to advance to MONT I.
Press the Page up button a second time to advance to
MONT RTD. As the table indicates, the motor bearing tem-
peratures are part of the MONT RTD page.
Press the Line up button to advance to winding tempera-
ture 1.
Press the Line up button six more times to advance to motor
bearing temperature 1. The display shows motor bearing
temperature 1 as MT1 XXXX, where XXXX is the actual
temperature
Press the Line up button again to advance to motor bearing
temperature 2.
Pressing the Line down button returns the display to the
previous Line, and pressing the Page down button returns the
display to the previous Page. The Value pushbuttons are not
used in the Monitor Mode.
These modes display the same information, but the settings cannot be
changed in the View Settings mode.
Pressing the View Settings pushbutton only displays the programmed
•
•
•
•
•
•
settings listed in Table 4.3. The displays and help messages are the
same as in the Program mode.
The Program mode permits the User to change the settings. Table 4.3
is a guide for programming; it is also a setting record sheet. Chapter 5
contains a description of the Program mode.
Pressing the History mode pushbutton displays the past history of the
motor as listed in Table 4.4.
For example, to view the number of under load trips and phase unbal-
ance trips:
• Press the History mode pushbutton; the display shows HIS-
TORY as listed at the top of Table 4.4.
• Press the Page up button twice to advance to HIST TRP.
• Press the Line up button ve times to advance to UL T XX,
where XX is the underload trip count since the last reset.
• Press the Value up button once to view the date of the last
reset, and a second time to view the time of the last reset.
Pressing the Value up button one more time returns the
display back to the underload trip count.
• Press the Line up button once to advance to UB T XX,
where XX is the number of phase unbalance trips since the
last reset.
• Repeatedly press the Value up button to cycle through the
date of reset, the time of reset, and the number of phase
unbalance trips.
