SPECIFICATIONS
EATON BladeUPS
®
(12 kVA) User's Guide S 164201649 Rev 4www.eaton.com/powerquality
100
Table 11. BladeUPS Bar 60
Dimensions (WxDxH) 140 x 161 x 1838 mm (6.3” x 4.4” x 72.4”)
Weight BladeUPS Bar: 19 kg (42 lb); Wireway enclosure: 20 kg (45 lb)
Total weight: 39 kg (87 lb)
UPS Connections Up to 6, using Anderson input/output connectors
Rack Placement Bottom wireway fits into the bottom 6U of standard rack space.
Top wireway fits into the top 6U of standard rack space.
Table 12. BladeUPS Module Rack
Dimensions (WxDxH) 610 x 1067 x 2032 mm (24” x 42” x 80”)
Weight Rack without side panels or casters: 99 kg (219 lb);
Side panels (each): 8.5 kg (19 lb); Casters (4): 5 kg (10 lb)
Total weight: 121 kg (267 lb)
Table 13. Electrical Input
BladeUPS 12 Module BladeUPS 12i Module
Nominal Voltage 120/208V three-phase 230/400V three-phase
Nominal Frequency 50/60 Hz 50/60 Hz
Frequency Range 45–65 Hz 45–65 Hz
Default Frequency Auto-detected Auto-detected
Rated Input Current 36A 24A
Connections
IEC 309-60A power cord IEC 309-32A power cord
For paralleling, a single Anderson input/output cord connects to the
BladeUPS Bar (see Table 9 on page 99).
Noise Filtering MOVs and common mode line filter
Input Power Factor High Efficiency setting: load dependent
Standard setting: >0.99
Input Mode Three-phase
