43
ENGINE
CS-370ES
CS-420ES
7 ENGINE
(A) Cylinder (Upper crankcase)
(B) Crankcase (Lower crankcase)
(C) Crankshaft assembly
(D) Ball bearing
(E) Oil seal
(F) Engine cover
(G) Piston ring
(H) Snap ring
(I) Piston
(J) Piston pin
(K) Needle bearing
(L) Piston pin spacer
(M) Intake bellows
(N) Intake gasket
(K)
(L)
(F)
(E)
(B)
(M)
(N)
(C)
(D)
(I)
(H)
(A)
(G)
(J)
