Using BIOS
For the purpose of better product maintenance, the manufacture reserves
the right to change the BIOS items presented in this manual. The BIOS
setup screens shown in this chapter are for reference only and may differ
from the actual BIOS. Please visit the manufacture’s website for updated
manual.
Standard CMOS Setup
This option displays basic information about your system.
Date Tue 12/01/2009
f
SATA1 Not Detected
SATA 2 Not Detected
SATA 3 Not Detected
SATA 4 Not Detected
SATA5 Not Detected
eSATA Not Detected
Help Item
f
f
f
CMOS Setup Utility -- Copyright (C) 1985-2005, American Megatrends, Inc.
Time 00:04:15
User [Enter], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Date.
Standard CMOS Setup
Date & Time
The Date and Time items show the current date and time on the computer. If you are
running a Windows OS, these items are automatically updated whenever you make
changes to the
Windows Date and Time Properties utility.
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Default settings
F1: General Help
IDE BusMaster Enabled
f
f
IDE Master/Slave, SATA1~5, eSATA
f
Your computer has one IDE channel which can be installed with one or two devices
(Master and Slave). In addition, this motherboard supports five SATA channels and
each channel allows one SATA device to be installed. Use these items to configure
each device on the SATA channel.
f
IDE Master Not Detected
IDE Slave
Not Detected
f
CMOS SETUP UTILITY – Copyright (C) 1985-2005, American Megatrends, Inc.
IDE Master
IDE Master
Type Auto
LBA/Large Mode
Block (Multi-Sector Transfer)
Auto
PIO Mode Auto
DMA Mode Auto
S.M.A.R.T Auto
32Bit Data Transfer Enabled
Help Item
Select thd type of device
connected to the system
Device : Not Detected
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Default settings
F1: General Help
Auto
To Next Page
