Hybrid Graphics

Technology Support

SurroundView

provides the power and convenience of multiadapter,

multimonitor support for computers that use a PCI-Express based

graphics card in conjunction with ATI integrated graphic processors.

And there are two options: Disabled and PCI Express.

If SurroundView

set to Disabled, and Init Display First set to

OnBoard, SurroundView

will be Enabled by Catalyst Control Center

based on cancel the Enable CrossFire

option.

While if display by OnBoard, you must enter the BIOS, set the Init Display First in

Advanced Chipset Setup to OnBoard. Then press F10 to save the configuration and

exit the BIOS. After entering OS, enter Catalyst Control Center to enable CrossFire

3. Click with your right mouse button on My Computer, then click the option

Manage and choose the Device Manager, finally, click the Display Adapters. The

following screen appears. Be sure that the external ATI graphics (ATI Radeon HD

3400 Grapics) and Onboard graphics (Radeon HD 4200) are both displaying in the

Display adapters.

Questions and Answers:

Need help?

Do you have a question about the ECS A785GM-AD3 and is the answer not in the manual?

ECS A785GM-AD3 Specifications

General

Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	8
Power fan connector	Yes
Number of SATA connectors	5
PS/2 ports quantity	2
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	-
Audio chip	Realtek ALC888S
Certification	ROHS, EuP
Motherboard chipset	AMD 785G
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Vista, 7
PCI slots	3
Maximum graphics card memory	512 MB
RAID levels	0, 1
LAN controller	Realtek RTL8111DL
Networking features	Gigabit Ethernet
BIOS type	AMI
BIOS memory size	64 Mbit
