Chapter 3
H61H2-TI USER MANUAL
35
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Main Advanced Chipset Frequency/Voltag Boot Security Exit
System Temperature : 50°C
CPU Fan Speed : 1251 RPM
System Fan Speed : 1779 RPM
CPU Voltage : 0.872V
AXG Voltage : 0.832 V
DIMM Voltage : 1.504 V
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -55
PC Health Status
+/- : Change Opt.
Enter : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
• System Temperature
• CPU Fan Speed
• System Fan Speed
• CPU Voltage
• AXG Voltage
• DIMM Voltage
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System temperature, CPU & DIMM voltage, CPU & System fan speed... etc.
Press <Esc> to return to the Advanced Menu page.
To Next Page
