SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Mode (IDE Mode)
Use this it
em to select SATA mode.
SATA Port1~2/mSATA
This motherboard supports two SATA channels and mSATA channel, each channel
allows one SATA device to be installed. Use these items to configure each device on
the SATA/mSATA channel.
Press <Esc> to return to the Advanced Menu page.
Main Advanced Chipset Frequency/Voltag Boot Security Exit
Determines how SATA
controller(s) operate.
SATA Configuration
SATA Mode IDE Mode
SATA Port1 WDC WD3200AAJS (320.0GB)
SATA Port2 Not Present
mSATA Not Present
+/- : Change Opt.
Enter : Select
: Select Screen
: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC : Exit
