Chapter 1
2
H61H2-TI USER MANUAL
CPU
Specifications
• Intel
®
H61 Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 2 x 204-pin DDR3 SO-DIMM sockets support up to 16 GB
• Supports DDR3 1333/1066 MHz DDR3 SDRAM
Memory
• 2 x mini PCI Express x1 slots
(the PCIE1 supports half-card, the PCIE2 supports full-card and
you can install a Mini SATA (mSATA) card into it)
• Supported by Intel
®
H61 Express Chipset
- 2 x Serial ATA 3Gb/s devices
- 1 x Mini SATA card
Expansion
Slots
Storage
• 1 x HDMI port
• 1 x HDMI_IN port (optional)
• 1 x 19V DC_IN port
• 1 x RJ45 LAN connector
• 2 x USB 2.0 ports
• 2 x USB 3.0 ports
• 1 x Audio port (1 x line-out, 1 x Microphone)
Rear Panel I/O
LAN • Realtek 8111E Gigabit LAN
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• Realtek ALC662
- 2 Channel High Definition Audio Codec
- Compliant with HD audio specification
Audio
• LGA1155 socket for
latest Intel
®
Core
TM
Family/Pentium
®
/
Celeron
®
Processors
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x USB 2.0 header supports additional two USB 2.0 ports
• 2 x Serial SATA 3Gb/s connectors
• 1 x Case open header
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
• 1 x ME enable/disable jumper
• 1 x Buzzer header
• 1 x LPC header
• 1 x SATA power connector
• 1 x Touch board header
• 1 x Consumer infrared
• 1 x Camera header
• 1 x Memory card reader header
• 1 x Digital Microphone header (optional)
• 1 x 2 channels audio speaker header (optional)
Internal I/O
Connectors &
Headers
• Asmedia ASM1042 supports two USB 3.0 ports
Extra Chips
