Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST (Enhanced Intel SpeedStep Tech-
nology).
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
Frequency/Voltag Menu
Chipset Advanced
Configuration
Main Advanced Chipset Frequency/Voltag Boot Security Exit
CPU OverClocking Configuration
Scroll to this item to view the following screen:
Enhanced Intel SpeedStep
Technology
Main Advanced Chipset Frequency/Voltag Boot Security Exit
CPU Frequency (100)
This item shows the information of CPU frequency.
CPU Ratio (27)
This item allows users to control non turbo CPU ratio.
Frequency/Voltage Control
CPU OverClocking Configuration
Chipset OverClocking Configuration
B.O.M.P. Technology Enabled
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Enabled
Intel(R) Core(TM) i5-3330S CPU @ 2.70GHz
Processor Speed 2700 MHz
Memory Frequency 1333 MHz
Total Memory 2048 MB (DDR3)
+/- : Change Opt.
Enter : Select


: Select Screen
: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC : Exit
+/- : Change Opt.
Enter : Select


: Select Screen
: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC : Exit
CPU Advanced Configuration
CPU Frequency 100
CPU Ratio 27
Enhanced Intel SpeedStep Technology Enabled
Turbo Mode Enabled
Runtime Turbo Enable Disabled
Over Clocking Extra Vol.(1/256 V) 0
1 Core Ratio Limit 32
2 Core Ratio Limit 31
3 Core Ratio Limit 29
4 Core Ratio Limit 28
Intel Graphics Configuration
Graphics Core Ratio Limit 21
Graphics Voltage(1/256) 0
