6-3. Attaching the original stand
1.
Lay the LCD monitor on a soft cloth spread over a stable and at surface with
the LCD panel surface facing down.
2.
Remove the xing screws on the optional arm (or optional stand), and detach
the optional arm (or optional stand).
3.
Attach the original stand.
Insert the four tabs on the stand into the four holes on the back panel (1), and slide the stand towards
the upper portion of the monitor (2). The stand clicks when it is attached correctly.
Click!
(1)
(2)
34
Chapter 6 Attaching/Removing the Stand
