Chapter 6 Reference
6-3. Specications
LCD Panel Type IPS (Anti-Glare)
Backlight LED
Size 48 cm (19 inch)
Native Resolution 1280 dots × 1024 lines
Display Size (H × V) 374.8 mm × 299.8 mm
Pixel Pitch 0.293 mm
Display Colors 8-bit colors: 16.77 million colors
Viewing Angle (H / V, typical) 178˚ / 178˚
Response Time (typical) Gray-to-gray: 14 ms
Video Signals Input Terminals DisplayPort (HDCP) × 1, DVI-D (HDCP) × 1, and D-Sub mini 15-
pin × 1
Digital Scanning Frequency
(H / V)
31 kHz to 64 kHz / 59 Hz to 61 Hz
Analog Scanning Frequency
(H / V)
31 kHz to 64 kHz / 55 Hz to 61 Hz
Synchronization Signal Separate
Max. Dot Clock 108 MHz
Audio Audio Input Format DisplayPort: 2ch linear PCM (32 kHz / 44.1 kHz /
48 kHz / 88.2 kHz / 96 kHz)
Speakers 0.5 W + 0.5 W
Headphones 2 mW + 2 mW (32 Ω)
Input Terminals Line: Stereo mini jack × 1
DisplayPort × 1 (shared with video signal)
Output Terminals Headphones: Stereo mini jack × 1
Power Input 100 - 240 VAC ±10 %, 50 / 60 Hz 0.4 A - 0.25 A
Maximum Power Consumption 21 W or less
Power Save Mode 0.5 W or less (default settings)
Standby Mode 0.5 W or less (default settings)
Physical
Specications
Dimensions Tilt Stand : 405 mm × 414 mm × 205 mm (W × H
× D)
Height adjustable Stand : 405 mm × 406.5 mm - 506.5 mm ×
205 mm (W × H × D)
Dimensions (Without Stand) 405 mm × 334 mm × 61.5 mm (W × H × D)
Net Weight Tilt Stand : Approx. 4.6 kg
Height adjustable Stand : Approx. 5.6 kg
Net Weight (Without Stand) Approx. 3.8kg
Height Adjustment Range Tilt Stand : -
Height adjustable Stand : 100 mm
Tilt Tilt Stand : Up 30˚, Down 5˚
Height adjustable Stand : Up 30˚, Down 0˚
Swivel Tilt Stand : -
Height adjustable Stand : Left 35˚, Right 35˚,
Vertical Rotation Tilt Stand : -
Height adjustable Stand : Clockwise 90˚
Operating
Environmental
Requirements
Temperature 5 ˚C to 35 ˚C (41 ˚F to 95 ˚F)
Humidity 20 % to 80 % R.H. (no condensation)
Air Pressure 540 hPa to 1060 hPa
