Eizo FLEXSCAN SX3031W User Manual

8
Chapter 1 Overview and Features
1-3 Functions and Basic Operation
To adjust the screen and color
• The Adjustment menu and the FineContrast menu cannot
be displayed at the same time.
Color adjustment
Simple adjustment [FineContrast mode]
This function allows easy selection of a desired mode
from fi ve modes according to monitor application.
●
After selecting the adjustment item by and ,
select values by
and .
●
“Brightness,” “Temperature,” and “Gamma” can be set
for each mode (Custom/Movie/Picture/Text/sRGB).
Settable functions vary with the display mode.
-/$%
FineContrast menu
Page 11
Brightness adjustment
Press or to adjust brightness.
Screen Adjustment
●
To modify blurred characters/lines
[Smoothing] ………………………… see page 15
Page 15
Color Adjustment
Advanced Adjustment
●
“Brightness,” “Temperature,” “Gamma,”
“Saturation,” “Hue,” “Gain,” and “6 Colors” can be
set for each mode (Custom/sRGB/Text/Picture/
Movie).
Settable functions vary with the display mode.
Resumption of Default Setting
●
To reset color adjustment [Reset] …see page 19
Page 12
Main menu (Refer to page 9 for operation)
SX3031W_UM_EN.indd 8SX3031W_UM_EN.indd 8 5/29/2007 1:46:00 PM5/29/2007 1:46:00 PM

Eizo FLEXSCAN SX3031W Specifications

General

Brand	Eizo
Model	FLEXSCAN SX3031W
Category	Monitor
Language	English
