Chapter 1 Overview and Features
Chapter 1 Features and Overview
Thank you very much for choosing an EIZO color LCD monitor.
1-1 Features
• 30 inch class wide screen format LCD
• WQXGA (2560 × 1600) display compliant (SIGNAL1)
• HDCP signal (SIGNAL2) compliant
• Dual-display compliant by introducing dual-input system (DVI-D × 2
connectors)
• DVI digital input (TMDS) compliant
• Horizontal scan frequency: 31 - 100 kHz
• Vertical scan frequency: 59 - 61 Hz (VGA TEXT: 69 - 71 Hz)
• Resolution: 2560 dots × 1600 lines
• Compatible with frame synchronization mode (59 - 61 Hz)
• Smoothing (soft - sharp) function
• FineContrast mode to allow the best mode for screen display
• The utility software “ScreenManager Pro for LCD” (for Windows) to control
the monitor from a PC with mouse/keyboard is included (refer to the EIZO
LCD Utility Disk).
1-2 Buttons and Indicators
Adjustment menu (*ScreenManager
®
)
Buttons
1. Input signal selection button
2. Mode button
3. Enter button
4. Control buttons (Left, Down, Up, Right)
5. Power button
6. Power indicator
Indicator status Operation status
Blue The screen is displayed
Orange Power saving
Off Power off
* ScreenManager
®
is an EIZO’s nickname of the Adjustment menu.
NOTE
• While the screen is displayed, the
blue power indicator that is lighting
blue can be turned off (see “To turn
off the Power indicator while a screen
is displayed [Power Indicator]” on
page 16).
• For the power indicator status with
“Off Timer” set, refer to “To set
monitor power-off time [Off Timer]”
on page 14.
