Commissioning
SwitchPanel
andAGUOperatingPanel
Des
cription

LCD
withbacklight

M
ultifunctiondatadisplayforvarious
devices,boiler,heatingandhotwater,
aswellaserrorcodesusingLCD
display

Dis
playwithtoggleswitchbetween
enduserandprofessionaluserlevels

Operatingphilosophysimilartoroom
deviceQAA73…

Integratedclockmoduledaytimeti-
merprogramforheatingcircuit1and
hotwaterwith3phases/day

Par
ametermodeofLMU6…for
TRIGON
OperatingElement Function Button
1 ButtonReset(unlock) UnlockingLMU…Ignitionmanager
2 ButtonDomesticwaterusemode DomesticwateruseON/OFF
3 ButtonSetmodeheatingcircuit Switchoperatingmodeto:
Automaticmode
Continuousmodeatnominallevel
Continuousmodeatreducedlevel
Freezeprotection
4 ButtonTargettemp.heatingcircuit Adjustmentfordesiredroomtemperature
5 ButtonTargettemp.domesticwateruse Adjustmentfordesireddomesticwater
temperature
6
7
ButtonsLineselector(down)and(up) Selectionofoperatingline
8
9
ButtonsAdjustmentofselectedvalue Readjustmentofsetupparameters
10 ButtonInformation Changeinformationdisplay
11 LCD-display Displayofdataandoperatingmodes
12 Chimneysweeper Chimneysweeperfunction/valvestop
(pushbothbuttons)
Pro
g
+
-
2113
45112678910
19
e
n
